1954 Bates B.A.R.
serial number 17148B, 23.75" seat tube ctt, 22.75" top tube ctc, 74° head tube, 71° seat tube, 40 7/8" wheelbase, Reynolds 531 double butted tubing, Cantiflex frame tubes (larger diameter thinner walls in middle), Diadrant forks (double curve), Nervex Professional lugs (fork crown D/B. Randonneur Feature Cut No. 7). Purchased from Peter Paine.
Components: Huret Tour de France rear gear; Huret lever front changer; Huret downtube shifter; Stronglight Competition cottered steel cranks; 48-52 Simplex black steel & alloy chainrings; four speed Regina G.S. Corse freewheel [16-19-23-28; 45-85 gear inches]; 3/32" Renold chain; Chater Lea Sprint pedals; GB Professionnel stainless steel toe clips; Resilion 40o free/fixed rear hub and 32o front hub; Sun CR18 700c rims; TDC headset; Beborex drillium sidepull brakes and Beborex brake levers; Jagwire X-Caliper brake pads; ribbed cable housing; 3" GB stem; GB handlebars; TA handlebar water bottle cage; Milremo handlebar plugs; Wrights Olympian 56L saddle; Ideale No. 3 saddle clamp; BW dometop steel 26.8mm seatpin
Weight: 26.5 pounds


hover your mouse over this image to magnify it or link directly to larger photo

hover your mouse over this image to magnify it or link directly to larger photo

hover your mouse over this image to magnify it or link directly to larger photo
