1983 Grandis
58cm seat tube ctc, 57cm top tube ctc, 39 3/16" wheelbase, Columbus tubing; 34 stamped on bottom bracket; 23 stamped on
steerer tube. Purchased from David "cheapcampy"
Components: Campagnolo Record crankarms and bottom bracket [70-SS axle];
53t Campagnolo Grandis-pantographed chainring; 41t anonymous chainring; Atom 77 Compact six speed freewheel
[13-15-17-20-24-28; 39 - 107 gear inches]; Regina Extra Oro chain;
Campagnolo Super Record rear derailleur pat. 1983; Campagnolo Super Record front derailleur;
Gipiemme Cronosprint retrofriction shifters;
Campagnolo Record Superleggeri pedals; Campagnolo alloy toe clips; Cinelli Binda toestraps;
Cinelli toestrap buttons;
Shimano 600 Grandis-pantographed 27.2mm seatpost; Campagnolo seatpost binder bolt; Concor Supercorsa 'Grandis' saddle;
Campagnolo Record brakes with relieved Grandis-pantographed brake levers & Campagnolo black shield logo brake hoods;
Campagnolo Record 36o hubs; Mavic Open4CD rims;
3ttt Grandis-pantographed stem with titanium binder bolt; 3ttt Mod. Competizione handlebars;
Grandis handlebar plugs; TA alloy water bottle cage; Grandis water bottle.
Bike dated to 1983 due to parts on bike when purchased & assumed original: black shield logo brake hoods [shield logo
introduced 1983]; Pat 1983 Nuovo Record rear derailleur; (2) on crankarms.
Weight: 22.1 pounds
hover your mouse over this image to magnify it or
link directly to larger photo
hover your mouse over this image to magnify it or
link directly to larger photo
hover your mouse over this image to magnify it or
link directly to larger photo
Marque:
Grandis Biciclette
Verona, Italy
Marque site:
Classic Rendevous
Visit to Grandis: Angelo senza la o Blog
